Iron-Hematoxylin Staining – Principle, Procedure, Uses

Hematoxylin is extracted from a leguminous plant, known as Haematoxylon campechianum, thus it is a natural dye. It forms hematein by oxidation (Ripening).

Summarise with AI:
  • Iron-hematoxylin staining is a permanent staining method used for the identification of intestinal protozoa in faecal specimens.
  • It is used to examine the nuclear and cytoplasmic structures of protozoan trophozoites and cysts.
  • The staining method uses hematoxylin and an iron salt, such as ferric ammonium sulphate. The iron salt acts as a mordant.
  • Hematoxylin is oxidised to hematein, which combines with iron to form a coloured complex.
  • The nuclear chromatin stains dark blue to black, while the cytoplasm appears in different shades of greyish blue.
  • A thin faecal smear is prepared and fixed before staining to preserve the morphology of protozoa.
  • In the regressive staining method, the smear is first overstained and then differentiated to remove the excess stain.
  • The staining method can be used with faecal specimens preserved in sodium acetate-acetic acid-formalin (SAF) and merthiolate-iodine-formalin (MIF).
  • There are different modifications of iron-hematoxylin staining, including the Heidenhain, Spencer-Monroe and Tompkins-Miller methods.
  • The stained smear is examined under a microscope using the 100× oil immersion objective. The slide can be stored for further examination.
  • Iron-hematoxylin staining is not generally used for the identification of helminth eggs and larvae, as these structures may stain too darkly or become distorted.

What is Iron-Hematoxylin Staining?

Iron-hematoxylin staining is a permanent staining method used for the detection and identification of intestinal protozoa in faecal specimens. It is used to examine the nuclear and cytoplasmic structures of protozoan trophozoites and cysts under a microscope.

The staining method uses hematoxylin and an iron salt, such as ferric ammonium sulphate (iron alum). Iron alum acts as a mordant and combines with oxidised hematoxylin to form a coloured complex. The nuclear structures are stained dark blue to black, while the cytoplasm appears in different shades of greyish blue.

Iron-hematoxylin staining is commonly used in parasitology for the identification of intestinal protozoa. It is also used in histology for staining tissue sections and examining the internal structures of cells.

Objectives of Iron-Hematoxylin Staining

The objectives of iron-hematoxylin staining are as follows:

  • To detect intestinal protozoa present in faecal specimens.
  • To identify the trophozoites and cysts of intestinal protozoa.
  • To examine the nuclear structures of protozoa, such as the karyosome and peripheral chromatin.
  • To observe the cytoplasmic structures and inclusions present in protozoan cells.
  • To differentiate intestinal protozoa based on their nuclear and cytoplasmic characteristics.
  • To detect small protozoa that may not be seen in wet mount preparations.
  • To prepare permanent stained slides for further examination and reference.

Principle of Iron-Hematoxylin Staining

Schematic showing hematoxylin oxidation to hematein, formation of an iron staining complex, overstaining and differentiation of a protozoan cell.
Iron alum acts as a mordant in iron-hematoxylin staining. Controlled differentiation removes excess stain while retaining dark nuclear detail.

The principle of iron-hematoxylin staining is based on the formation of a coloured complex between hematoxylin and an iron salt. Hematoxylin is first oxidised to hematein. Ferric ammonium sulphate (iron alum) acts as a mordant and combines with hematein to form an iron-hematein complex.

In Heidenhain’s iron-hematoxylin staining, the fixed smear is treated with iron alum and then stained with hematoxylin. The smear is first overstained and then differentiated using iron alum. During differentiation, the excess stain is removed from the specimen.

The nuclear chromatin retains the stain and appears dark blue to black, while the cytoplasm is stained in different shades of greyish blue. The degree of differentiation affects the staining intensity of the nuclear and cytoplasmic structures.

Reagents and Materials Required for Iron-Hematoxylin Staining

The following are the reagents and materials required for iron-hematoxylin staining by Heidenhain’s method:

Reagents Required

  1. Hematoxylin Solution – It is prepared by dissolving 0.30 g of hematoxylin in 100 mL of distilled water. The solution is allowed to ripen before use.
  2. Iron Alum Solution – It contains 2 g of ferric ammonium sulphate dissolved in 98 mL of distilled water. It is used as a mordant and for differentiation.
  3. Schaudinn’s Fixative – It is used for the fixation of faecal smears. The traditional solution contains mercuric chloride, ethanol, and acetic acid.
  4. Iodine Solution – It is used to remove mercury deposits from the smears fixed with mercuric chloride-containing fixatives.
  5. Ethyl Alcohol – 70–95% ethanol and absolute ethanol are used for dehydration of the stained smear.
  6. Xylene – It is used as a clearing agent before mounting the stained smear.
  7. Distilled Water – It is used for the preparation of staining solutions.
  8. Mounting Medium – A suitable mounting medium, such as DPX, is used for the preparation of permanent slides.

Materials Required

  1. Faecal Specimen – Fresh faecal samples containing intestinal protozoa are required for staining.
  2. Glass Slides – Clean glass slides are used for the preparation of thin faecal smears.
  3. Coverslips – These are used to cover the stained smear after mounting.
  4. Staining Jars – Coplin jars or other suitable staining containers are used to hold the staining solutions.
  5. Droppers or Pipettes – These are used to transfer staining reagents and faecal samples.
  6. Forceps – They are used to hold and transfer glass slides during staining.
  7. Staining Rack – It is used to hold the glass slides during washing and staining.
  8. Light Microscope – A compound light microscope with a 100× oil immersion objective is required for the examination of stained smears.
  9. Immersion Oil – It is used for microscopic examination of the stained smear under the 100× oil immersion objective.

Procedure of Iron-Hematoxylin Staining

Iron-hematoxylin staining can be carried out by different methods. The following are the methods used for staining intestinal protozoa:

1. Heidenhain’s Iron-Hematoxylin Staining

Laboratory workflow showing fixation, iodine treatment, iron alum mordanting, hematoxylin staining, differentiation, dehydration, mounting and oil-immersion microscopy.
The shortened Heidenhain method uses separate iron-alum and hematoxylin treatments, with differentiation when required, before dehydration, clearing and mounting.

The procedure of the shortened Heidenhain’s iron-hematoxylin staining method is given below:

  1. Prepare a thin faecal smear on a clean glass slide and immediately place it in Schaudinn’s fixative for at least 1 minute while the smear is still wet.
  2. Wash the slide in three changes of tap water.
  3. Transfer the slide to 70–95% ethanol and then place it in iodine-alcohol solution for 1 minute to remove mercury deposits.
  4. Place the slide in 70–95% ethanol for another 1 minute to remove the iodine.
  5. Wash the slide in three changes of tap water.
  6. Place the slide in 2% ferric ammonium sulphate solution for about 30 seconds.
  7. Wash in four to five changes of tap water.
  8. Stain the smear with 0.3% aqueous hematoxylin solution for 3–5 minutes.
  9. Rinse the slide in three changes of water.
  10. If the smear is overstained, immerse it briefly in the iron alum solution for differentiation and wash in three to five changes of tap water.
  11. Dehydrate the slide in 70–95% ethanol for about 2 minutes, followed by 95% ethanol and two changes of absolute ethanol for 2 minutes each.
  12. Clear the slide in xylene and mount it using a suitable mounting medium and coverslip.
  13. Examine the stained smear under a microscope using the 100× oil immersion objective.

2. Spencer-Monroe Iron-Hematoxylin Staining

In the Spencer-Monroe method, the hematoxylin solution is mixed with an iron mordant to prepare the working staining solution. The procedure for mercuric chloride-based PVA-preserved faecal smears is given below:

  1. Prepare a thin smear from the preserved faecal specimen and allow it to dry completely.
  2. Place the slide in 70% ethanol for 5 minutes.
  3. Transfer the slide to iodine-alcohol solution prepared with 70% ethanol for 2–5 minutes.
  4. Place the slide in 70% ethanol for another 5 minutes.
  5. Wash the slide in running tap water for 10 minutes.
  6. Stain the smear with the working iron-hematoxylin solution for 4–5 minutes. The working stain contains equal volumes of ripened hematoxylin solution and iron mordant solution.
  7. Wash in running tap water for 10 minutes.
  8. Transfer the slide to 70% ethanol for 5 minutes.
  9. Place the slide in 95% ethanol for 5 minutes.
  10. Dehydrate the slide in two changes of absolute ethanol for 5 minutes each.
  11. Clear the slide in two changes of xylene for 5 minutes each.
  12. Add a suitable mounting medium and cover the smear with a coverslip.
  13. Examine the slide under the 100× oil immersion objective.

For SAF-fixed specimens, the iodine-alcohol treatment is omitted. The dried smear is placed in 70% ethanol before washing and staining.

3. Tompkins-Miller Iron-Hematoxylin Staining

The Tompkins-Miller method uses phosphotungstic acid for differentiation of the stained smear. The procedure for mercuric chloride-fixed faecal smears is given below:

  1. Prepare a thin faecal smear on a clean glass slide and fix it using a suitable fixative.
  2. Place the fixed slide in 70% ethanol for 5 minutes.
  3. Transfer the slide to iodine-alcohol solution for 2–5 minutes.
  4. Place the slide in 50% ethanol for 5 minutes.
  5. Wash the slide in running tap water for 3 minutes.
  6. Transfer the slide to 4% ferric ammonium sulphate solution for 5 minutes.
  7. Wash the slide in running tap water for 1 minute.
  8. Stain the smear with 0.5% aqueous hematoxylin solution for 2 minutes.
  9. Rinse in tap water for 1 minute.
  10. Place the slide in 2% phosphotungstic acid for 2–5 minutes to remove the excess stain.
  11. Wash the slide in running tap water for 10 minutes.
  12. Transfer the slide to 70% ethanol containing a few drops of saturated aqueous lithium carbonate solution for 3 minutes.
  13. Place the slide in 95% ethanol for 5 minutes.
  14. Dehydrate the slide in two changes of absolute ethanol for 5 minutes each.
  15. Clear the slide in two changes of xylene for 5 minutes each.
  16. Mount the stained smear with a suitable mounting medium and coverslip.
  17. Examine the slide under a microscope using the 100× oil immersion objective.

For SAF-fixed or other non-mercury-fixed smears, the initial iodine-alcohol treatment is omitted. Staining begins with the 50% ethanol step.

Comparison of three iron-hematoxylin staining methods showing separate iron-alum treatment, mixed working stain and phosphotungstic-acid differentiation.
Heidenhain uses separate mordant and staining stages, Spencer-Monroe uses a mixed working stain, and Tompkins-Miller incorporates phosphotungstic acid for differentiation.

Result and Interpretation of Iron-Hematoxylin Staining

Result of Iron-Hematoxylin Staining

The stained smear is examined under a microscope using the 100× oil immersion objective. The following are the results of iron-hematoxylin staining:

  • The nuclei and nuclear chromatin of protozoa appear dark blue to black.
  • The karyosome and peripheral chromatin are stained black and can be clearly observed.
  • The cytoplasm of trophozoites and cysts appears in different shades of greyish blue.
  • The chromatoid bodies and some cytoplasmic inclusions stain dark blue to black.
  • The background faecal material appears light blue to grey.

Interpretation of Iron-Hematoxylin Staining

The results of iron-hematoxylin staining are interpreted as follows:

  • The presence of protozoan trophozoites or cysts in the stained smear indicates the presence of intestinal protozoa in the specimen.
  • The number of nuclei, position of the karyosome and arrangement of peripheral chromatin are used for the identification of different intestinal protozoa.
  • The cysts of Entamoeba histolytica and Entamoeba dispar cannot be differentiated by their morphological characteristics alone. The presence of ingested red blood cells in trophozoites supports the identification of E. histolytica.
  • If no protozoa are observed after examining at least 300 oil immersion fields, the smear is reported as negative. A negative result does not exclude the presence of intestinal protozoa in the patient.
  • If the nuclear and cytoplasmic structures are not clearly visible, the smear may be overstained or excessively differentiated.
Iron-hematoxylin-stained amoebic trophozoite with one nucleus beside a mature four-nucleated cyst, showing karyosomes, peripheral chromatin and grey-blue cytoplasm.
Iron-hematoxylin staining demonstrates the nuclear and cytoplasmic morphology of intestinal protozoa. Nuclear number, karyosome position and peripheral chromatin help identify morphological groups, but cannot reliably distinguish E. histolytica from E. dispar or E. moshkovskii.

Uses of Iron-Hematoxylin Staining

The following are the uses of iron-hematoxylin staining:

  • It is used for the detection and identification of intestinal protozoa in faecal specimens.
  • It is used to examine the trophozoites and cysts of intestinal amoebae and flagellates.
  • The nuclear structures, such as the karyosome and peripheral chromatin, can be examined using this staining method.
  • It is used to observe the cytoplasmic structures, chromatoid bodies and ingested red blood cells present in protozoa.
  • Small protozoa that may be missed during wet mount examination can be detected in permanent stained smears.
  • It is used to differentiate intestinal protozoa based on their morphological characteristics.
  • Permanent stained slides can be stored for reference, teaching and further microscopic examination.

Limitations of Iron-Hematoxylin Staining

The following are the limitations of iron-hematoxylin staining:

  • The method requires several steps and takes more time than trichrome staining.
  • Proper fixation of the specimen is required. If fixation is delayed, the protozoan trophozoites may become distorted.
  • Excessive differentiation removes the stain from the nuclear structures, while insufficient differentiation leaves the smear too dark.
  • The stained structures appear in different shades of greyish blue. The colour contrast between protozoa and faecal debris is less than in trichrome staining.
  • It cannot differentiate Entamoeba histolytica, E. dispar and E. moshkovskii based on their morphological characteristics alone.
  • Helminth eggs and larvae may stain too darkly or become distorted. The method is not suitable for their identification.
  • Routine iron-hematoxylin staining does not reliably detect coccidian oocysts and microsporidian spores. Special staining methods are required for their detection.
  • Intestinal protozoa may be present in small numbers and may not be seen in the smear. A negative result does not exclude their presence.
  • An experienced microscopist and a microscope with a 100× oil immersion objective are required for examining the stained smears.
  • Some traditional methods use fixatives containing mercuric chloride, which require special handling and disposal.

Advantages of Iron-Hematoxylin Staining

The following are the advantages of iron-hematoxylin staining:

  • The nuclear structures of intestinal protozoa are clearly stained, which helps in their identification.
  • It helps to examine the karyosome, peripheral chromatin and other nuclear details of protozoa.
  • The cytoplasmic structures and inclusions present in trophozoites and cysts can also be observed.
  • Small protozoa that may not be seen in wet mount preparations can be detected in permanently stained smears.
  • It is suitable for staining faecal specimens preserved in different fixatives, including SAF and MIF.
  • The staining method can be used for the identification of both trophozoites and cysts of intestinal protozoa.
  • The stained slides can be stored for a long time and used for further examination, teaching and reference.

References

  1. Ferreira, C. S. (2003). Staining of intestinal protozoa with Heidenhain’s iron hematoxylin. Revista do Instituto de Medicina Tropical de São Paulo, 45(1), 43–44. https://doi.org/10.1590/S0036-46652003000100009
  2. Garcia, L. S. (2016). Diagnostic medical parasitology (6th ed.). ASM Press. https://doi.org/10.1128/9781555819002
  3. Garcia, L. S. (2021). Practical guide to diagnostic parasitology (3rd ed.). ASM Press. https://doi.org/10.1128/9781683673637
  4. Garcia, L. S., Arrowood, M., Kokoskin, E., Paltridge, G. P., Pillai, D. R., Procop, G. W., Ryan, N., Shimizu, R. Y., & Visvesvara, G. (2018). Practical guidance for clinical microbiology laboratories: Laboratory diagnosis of parasites from the gastrointestinal tract. Clinical Microbiology Reviews, 31(1), e00025-17. https://doi.org/10.1128/CMR.00025-17
  5. Shetty, N., & Prabhu, T. (1988). Evaluation of faecal preservation and staining methods in the diagnosis of acute amoebiasis and giardiasis. Journal of Clinical Pathology, 41(6), 694–699. https://doi.org/10.1136/jcp.41.6.694
  6. Spencer, F. M., & Monroe, L. S. (1982). The color atlas of intestinal parasites (2nd ed.). Charles C Thomas. https://agris.fao.org/search/en/providers/122535/records/65de03fc4c5aef494fd8b21f
  7. Tompkins, V. N., & Miller, J. K. (1947). Staining intestinal protozoa with iron-hematoxylin phosphotungstic acid. American Journal of Clinical Pathology, 17(9), 755–758. https://doi.org/10.1093/ajcp/17.9_ts.755
