Calcofluor White Staining – Principle, Procedure, Results and Uses

Calcofluor White staining is a fluorescent staining technique used for the detection of fungal elements in clinical and laboratory specimens. The staining reagent used in this method is Calcofluor White (CFW), also known as Fluorescent Brightener 28. The specimen is placed on a clean glass slide and Calcofluor White reagent is added to it. Potassium hydroxide (KOH) may also be added to clear the material present in certain specimens. The preparation is then covered with a coverslip and examined under a fluorescence microscope using suitable excitation and emission filters.

Calcofluor White staining is commonly used for the direct examination of skin scrapings, hair, nails and other specimens suspected of containing fungal elements. It is also used for staining yeast cells and plant cell walls. The staining concentration, incubation time, washing steps and sample preparation may differ from those used in the routine fungal wet-mount method. KOH is not required in all staining procedures.

Purpose of Calcofluor White Staining

The following are the purposes of Calcofluor White staining:

• To detect the presence of fungal elements such as hyphae and yeast cells in clinical and laboratory specimens.
• It is used to observe fungal cell walls containing chitin and other polysaccharides that bind to Calcofluor White.
• To examine the structure and arrangement of yeast cells, including budding cells and pseudohyphae, under a fluorescence microscope.
• Calcofluor White staining is also used for the detection of cysts of certain microorganisms, such as Acanthamoeba and Pneumocystis jirovecii.
• It is used for rapid microscopic screening of specimens suspected of containing fungal elements.
• To increase the contrast between the stained fungal structures and the surrounding material during fluorescence microscopy.
• To examine chitin-containing and other susceptible polysaccharide-rich structures that can be stained with Calcofluor White.
• The staining method helps in the detection and observation of fungal structures, but it cannot be used alone for definitive identification of fungal species. Further laboratory tests are required for species identification.

Principle of Calcofluor White Staining

Calcofluor White (CFW) staining is based on the binding of a fluorescent dye to certain polysaccharides present in cell walls. When the stained specimen is exposed to ultraviolet or violet light, the bound dye produces fluorescence. The fluorescent structures are then observed under a fluorescence microscope.

Binding of Calcofluor White to Cell-Wall Polysaccharides

Calcofluor White binds to certain polysaccharides containing β-1,3 and β-1,4 glycosidic linkages. It has an affinity for chitin and certain β-glucans present in fungal cell walls, including those of yeast cells. Chitin consists of N-acetylglucosamine units joined by β-1,4 glycosidic linkages.

The dye also binds to cellulose and other susceptible polysaccharides present in plant and algal cell walls. Cellulose is not commonly found in fungal cell walls. Calcofluor White is not specific to fungi, as it can also stain certain non-fungal structures.

Excitation and Emission Wavelengths of Calcofluor White

Calcofluor White absorbs light mainly in the near-ultraviolet region, with excitation commonly around 355–380 nm. When exposed to this light, the dye emits fluorescence mainly in the blue region. Under certain conditions, the maximum emission occurs near 430–435 nm.

A fluorescence microscope with suitable excitation and emission filters is required for the observation of stained structures. UV or DAPI-type filter sets are commonly used. The excitation filter allows light of the required wavelength to reach the specimen, while the emission filter allows the emitted fluorescence to pass through for observation.

The fluorescence produced by Calcofluor White is mainly blue. However, the stained structures may appear blue, blue-white or apple-green depending upon the filters and optical settings of the microscope.

The intensity of fluorescence depends upon the amount of dye bound to the specimen, the excitation light and the filters used. Other materials present in the specimen may also produce background fluorescence and affect the contrast between the stained structures and the surrounding material.

Reagents and Materials Required for Calcofluor White Staining

The following are the reagents and materials required for Calcofluor White staining. The staining reagents and their concentrations depend upon the type of specimen and the method used.

Reagents and Working Concentrations

1. Calcofluor White staining solution- Calcofluor White M2R, also known as Fluorescent Brightener 28, is the main staining reagent. One commercially prepared solution contains 1 g/L (0.1% w/v) Calcofluor White M2R and 0.5 g/L Evans blue.
2. Potassium hydroxide (KOH)- A 10% KOH solution is used for clearing skin scrapings, hair, nails and other suitable specimens before microscopic examination. It is not required for all staining methods.
3. Evans blue- It is used as a counterstain in certain Calcofluor White solutions to reduce background fluorescence. Some commercial staining solutions already contain Evans blue.
4. Distilled water or suitable buffer- Used for the preparation and dilution of staining reagents. Distilled water is also required for washing specimens in certain staining protocols.

The concentration of Calcofluor White differs according to the staining method. The 1 g/L (0.1% w/v) concentration is present in one commercial formulation and is not the final working concentration for every specimen.

For yeast cell staining, a 1 mg/mL Calcofluor White stock solution may be diluted to 50 µg/mL (0.005% w/v) in the mounting medium. Plant tissue sections may be stained using a 0.01% (w/v) solution. In fungal wet-mount preparations, the final concentration also depends upon the amount of staining solution mixed with the specimen and KOH.

The storage conditions depend upon the reagent preparation. Certain commercial staining solutions are stored at room temperature, while some laboratory-prepared stock solutions are stored at 4°C. Calcofluor White solutions should be protected from light and stored according to the manufacturer’s instructions.

Materials and Equipment

1. Clean glass slides and coverslips for preparing the specimen.
2. Sterile swabs, forceps, scraping tools and specimen collection containers, depending upon the type of sample.
3. Sample tubes, droppers, micropipettes and pipette tips for transferring specimens and staining reagents.
4. A fluorescence microscope fitted with a suitable UV or violet light source and appropriate excitation and emission filters. UV or DAPI-type filter sets are commonly used.
5. Disposable gloves, laboratory coat and protective eyewear for handling clinical specimens and staining reagents.

Procedure of Calcofluor White Staining

Calcofluor White Staining Procedure for Fungi

The procedure of Calcofluor White staining for fungal specimens using a commercial staining solution is given below:

1. Take a small amount of the suspected fungal specimen and place it on a clean glass slide.
2. Add one drop of Calcofluor White staining solution to the specimen.
3. One drop of 10% potassium hydroxide (KOH) solution may also be added when clearing of keratinized material or specimen debris is required.
4. The preparation is then covered with a clean coverslip.
5. Allow the slide to stand for about 1 minute at room temperature.
6. Examine the slide for fungal elements under a fluorescence microscope at 100×–400× magnification using suitable UV illumination and excitation and emission filters.

The 1-minute standing time is used for the commercial staining method described here. Some specimens may require a longer clearing time or different preparation conditions. KOH is not required for all specimens.

Calcofluor White Staining Procedure for Yeast Cells

Calcofluor White staining is used to examine chitin present in yeast cell walls and bud scars. The procedure for fixed Candida albicans cells is given below:

1. Prepare a cell suspension from a culture of Candida albicans.
2. Fix the cells with formaldehyde at a final concentration of 3.7% for 45 minutes at 30°C.
3. The fixed cells are washed twice with water to remove the excess fixative.
4. Resuspend the cells in 0.5 mL of Calcofluor White staining solution containing 1 mg/mL of the dye.
5. Incubate the cell suspension for 5 minutes at room temperature.
6. Wash the stained cells twice with water to remove the unbound dye.
7. The cells are then prepared for microscopic examination. In this method, the cell walls and bud scars are observed using a confocal microscope with 405 nm laser excitation.

Other yeast species may require different staining concentrations, incubation times, fixation and washing conditions.

Calcofluor White Staining Procedure for Plant Cells

Calcofluor White staining of plant cells is used for the examination of cellulose-rich cell walls rather than fungal elements. The procedure for fixed plant tissue sections is given below:

1. Prepare thin sections of the plant tissue for staining.
2. Wash the fixed tissue sections under running tap water for 15–30 minutes.
3. Prepare a 0.01% (w/v) aqueous solution of Calcofluor White M2R.
4. Place the tissue sections in the staining solution for 5 minutes at room temperature. Keep the preparation protected from light during staining.
5. Rinse the stained sections with distilled water to remove the excess dye. Thick sections may require at least 10 washes.
6. Transfer the tissue sections onto a clean glass slide and mount them in water or glycerol.
7. Place a coverslip over the preparation.
8. Examine the stained cell walls under a fluorescence microscope using UV excitation at 340–380 nm and a suitable emission filter, such as a long-pass filter above 420 nm.

The staining concentration and time may differ depending upon the type and thickness of the plant tissue.

Results and Interpretation of Calcofluor White Staining

Microscopic Observations

The stained specimen is examined under a fluorescence microscope using suitable UV illumination and filters. The observations of Calcofluor White staining are as follows:

1. Fungal hyphae appear as bright fluorescent filaments. The septa and branching of the hyphae may also be observed.
2. Yeast cells show fluorescent cell-wall outlines. Budding yeast cells and pseudohyphae may be seen in suitable specimens.
3. In yeast cell-wall studies, bud scars may appear as bright fluorescent rings or spots due to the presence of chitin.
4. The walls of certain cyst-forming microorganisms, such as Acanthamoeba, may also show fluorescence.
5. Plant cell walls are stained due to the presence of cellulose and other susceptible polysaccharides.
6. The stained structures may appear bright blue, bluish-white or green depending upon the excitation and emission filters used.
7. Some tissue components and specimen debris may also show background fluorescence. This can make the observation of fungal structures difficult.

Interpretation of Results

The interpretation of Calcofluor White staining depends upon the fluorescence and morphology of the structures observed.

A positive result is indicated by the presence of characteristic fluorescent structures in the specimen. The shape, size, septation and branching pattern of fungal elements are also examined. Fluorescence alone cannot identify a particular fungal species.

A negative result indicates that no characteristic fluorescent structures were observed in the examined preparation. Fungal elements may not be detected when the number of organisms is low or the staining is weak.

Certain fibers, tissue components and stain deposits may resemble fungal structures. The morphology of these materials should be examined carefully. Positive and negative staining controls may also be used to check the staining reagents. Further examination by fungal culture, histopathology or molecular methods may be required for confirmation of the organism.

Applications of Calcofluor White Staining

The following are the applications of Calcofluor White staining:

• It is used for the rapid detection of fungal elements in clinical specimens such as skin scrapings, hair and nails.
• To examine suspected fungal infections, including dermatophytosis and fungal keratitis.
• Fungal hyphae and yeast cells present in clinical specimens and tissue sections can be observed under a fluorescence microscope.
• It is used to examine the structure and arrangement of fungal hyphae, including their septa and branching patterns.
• Calcofluor White is used to stain chitin present in fungal cell walls. In yeast cells, the bud scars and septa can also be observed.
• To study the distribution of chitin and changes in cell-wall formation in fungi.
• It is used for the detection of Acanthamoeba cysts in corneal scrapings and other suitable specimens.
• Detection of cyst forms of Pneumocystis jirovecii in respiratory specimens, including bronchoalveolar lavage samples.
• It is used to stain cellulose-rich cell walls of plant and algal cells for examination under a fluorescence microscope.
• Calcofluor White staining is also used in environmental microbiology to examine fungal hyphae present in soil samples.

Advantages of Calcofluor White Staining

The following are the advantages of Calcofluor White staining:

• It is a rapid staining method used for the detection of fungal elements in clinical specimens.
• The stained fungal structures show bright fluorescence and can be easily observed against the surrounding material.
• It helps in the detection of fungal hyphae and yeast cells that may be difficult to observe under an ordinary light microscope.
• Calcofluor White can be used with potassium hydroxide (KOH) to clear keratinized material and increase the contrast between fungal elements and specimen debris.
• In some studies, Calcofluor White staining has shown higher sensitivity than the conventional KOH wet-mount method.
• It can be used for the direct examination of skin scrapings, nail specimens, corneal scrapings and tissue sections.
• The staining method helps in observing the shape, branching and septation of fungal hyphae.
• It is used to stain chitin present in yeast cell walls. The bud scars and dividing septa can also be observed in suitable preparations.
• Calcofluor White staining can be used for faster examination of tissue specimens compared to periodic acid-Schiff (PAS) and Gomori methenamine silver (GMS) staining.
• It is also used for the examination of cellulose-rich plant cell walls and certain other polysaccharide-containing structures.

Limitations of Calcofluor White Staining

The following are the limitations of Calcofluor White staining:

• Calcofluor White can also stain non-fungal materials such as cotton fibres and cellulose-containing plant tissues. The stain is not specific to fungi.
• Collagen, elastin and keratin present in tissue specimens may also show fluorescence. This background fluorescence can make it difficult to observe the fungal elements.
• A particular fungal species cannot be identified by fluorescence alone. Fungal culture or other diagnostic tests may be required for identification.
• A negative staining result does not exclude fungal infection. When only a small number of fungal elements are present, they may not be detected.
• False-negative results may occur due to improper collection of specimens or uneven distribution of fungal elements in the sample.
• Some fungi show weak fluorescence with Calcofluor White staining. Candida glabrata and certain darkly pigmented fungi may be difficult to detect.
• A fluorescence microscope with suitable UV illumination and filters is required. This equipment is expensive and may not be available in all laboratories.
• Fluorescent fibres, debris and other artifacts may resemble fungal structures. Experience is required to differentiate them during microscopic examination.
• The fluorescence may decrease during prolonged microscopic examination or when the stained slides are examined after a delay, particularly in thin tissue sections.
• Improper staining or insufficient clearing of keratinized material may affect the observation of fungal elements. Unsuitable microscope settings can also make the structures difficult to observe.

Precautions of Calcofluor White Staining

The following are the precautions of Calcofluor White staining:

• Use clean, grease-free glass slides and coverslips for preparing the specimen.
• Avoid contamination of the specimen with cotton fibres, dust and other materials that may show fluorescence under the microscope.
• Use Calcofluor White staining solution of the appropriate concentration. The concentration may differ for fungal, yeast and plant specimens.
• Check the staining reagents before use. Contaminated Calcofluor White or KOH solutions may give false-positive results.
• Use potassium hydroxide (KOH) only when clearing of the specimen is required. Avoid adding too much KOH solution, as the coverslip may float.
• Place the coverslip carefully over the specimen to avoid air bubbles. Do not apply excessive pressure on the coverslip.
• Allow sufficient time for clearing when KOH is used. Do not allow the preparation to dry, as KOH crystals may form and interfere with the observation of fungal elements.
• Avoid excessive heating of the slide during clearing.
• Store Calcofluor White staining solution according to the manufacturer’s instructions and protect it from light. Certain laboratory-prepared solutions are stored at 4°C.
• Use a fluorescence microscope with suitable UV excitation and emission filters. Avoid direct exposure of the eyes and skin to ultraviolet light.
• Examine the stained preparation as soon as possible and avoid prolonged exposure to the excitation light.
• Use positive and negative staining controls when required, especially when a new batch of staining solution is prepared.
• Wear gloves, a laboratory coat and protective eyewear while handling Calcofluor White, KOH and clinical specimens. Avoid direct contact of the staining reagents with the skin and eyes.
• Dispose of used slides, clinical specimens and staining reagents according to laboratory safety procedures.
• Do not identify fungal organisms based on fluorescence alone. Examine the morphology of the stained structures and use additional diagnostic tests when required.

References

1. Arffa, R. C., Avni, I., Ishibashi, Y., Robin, J., & Kaufman, H. E. (1985). Calcofluor and ink-potassium hydroxide preparations for identifying fungi. American Journal of Ophthalmology, 100(5), 719–723. https://doi.org/10.1016/0002-9394(85)90629-4
2. Baselski, V. S., Robison, M. K., Pifer, L. W., & Woods, D. R. (1990). Rapid detection of Pneumocystis carinii in bronchoalveolar lavage samples by using Cellufluor staining. Journal of Clinical Microbiology, 28(2), 393–394. https://doi.org/10.1128/JCM.28.2.393-394.1990
3. Chander, J., Chakrabarti, A., Sharma, A., Saini, J. S., & Panigarhi, D. (1993). Evaluation of Calcofluor staining in the diagnosis of fungal corneal ulcer. Mycoses, 36(7–8), 243–245. https://doi.org/10.1111/j.1439-0507.1993.tb00758.x
4. Elhardt, C., Schweikert, R., Hartmann, L. M., Vounotrypidis, E., Kilani, A., Wolf, A., & Wertheimer, C. M. (2023). The role of the calcofluor white staining in the diagnosis of Acanthamoeba keratitis. Journal of Ophthalmic Inflammation and Infection, 13, Article 23. https://doi.org/10.1186/s12348-023-00345-2
5. Elorza, M. V., Rico, H., & Sentandreu, R. (1983). Calcofluor white alters the assembly of chitin fibrils in Saccharomyces cerevisiae and Candida albicans cells. Journal of General Microbiology, 129(5), 1577–1582. https://doi.org/10.1099/00221287-129-5-1577
6. Hageage, G. J., & Harrington, B. J. (1984). Use of Calcofluor White in clinical mycology. Laboratory Medicine, 15(2), 109–112. https://doi.org/10.1093/labmed/15.2.109
7. Haldane, D. J. M., & Robart, E. (1990). A comparison of calcofluor white, potassium hydroxide, and culture for the laboratory diagnosis of superficial fungal infection. Diagnostic Microbiology and Infectious Disease, 13(4), 337–339. https://doi.org/10.1016/0732-8893(90)90027-S
8. Harrington, B. J., & Hageage, G. J. (2003). Calcofluor White: A review of its uses and applications in clinical mycology and parasitology. Laboratory Medicine, 34(5), 361–367. https://doi.org/10.1309/EPH2TDT8335GH0R3
9. Harrington, B. J. (2008). Staining of cysts of Pneumocystis jiroveci (P. carinii) with the fluorescent brighteners Calcofluor White and Uvitex 2B: A review. Laboratory Medicine, 39(12), 731–735. https://doi.org/10.1309/LM5JZX8FTIGBW2SF
10. Hughes, J., & McCully, M. E. (1975). The use of an optical brightener in the study of plant structure. Stain Technology, 50(5), 319–329. https://doi.org/10.3109/10520297509117082
11. Kitin, P., Nakaba, S., Hunt, C. G., Lim, S., & Funada, R. (2020). Direct fluorescence imaging of lignocellulosic and suberized cell walls in roots and stems. AoB PLANTS, 12(4), Article plaa032. https://doi.org/10.1093/aobpla/plaa032
12. Lynch, D. P., & Gibson, D. K. (1987). The use of Calcofluor white in the histopathologic diagnosis of oral candidiasis. Oral Surgery, Oral Medicine, and Oral Pathology, 63(6), 698–703. https://doi.org/10.1016/0030-4220(87)90373-2
13. Marines, H. M., Osato, M. S., & Font, R. L. (1987). The value of calcofluor white in the diagnosis of mycotic and Acanthamoeba infections of the eye and ocular adnexa. Ophthalmology, 94(1), 23–26. https://doi.org/10.1016/S0161-6420(87)33516-X
14. Monheit, J. G., Brown, G., Kott, M. M., Schmidt, W. A., & Moore, D. G. (1986). Calcofluor white detection of fungi in cytopathology. American Journal of Clinical Pathology, 85(2), 222–225. https://doi.org/10.1093/ajcp/85.2.222
15. Pringle, J. R. (1991). Staining of bud scars and other cell wall chitin with calcofluor. In C. Guthrie & G. R. Fink (Eds.), Guide to yeast genetics and molecular biology (Methods in Enzymology, Vol. 194, pp. 732–735). Academic Press. https://doi.org/10.1016/0076-6879(91)94055-H
16. Procop, G. W., Haddad, S., Quinn, J., Wilson, M. L., Henshaw, N. G., Reller, L. B., Artymyshyn, R. L., Katanik, M. T., & Weinstein, M. P. (2004). Detection of Pneumocystis jiroveci in respiratory specimens by four staining methods. Journal of Clinical Microbiology, 42(7), 3333–3335. https://doi.org/10.1128/JCM.42.7.3333-3335.2004
17. Rane, H. S., Hayek, S. R., Frye, J. E., Abeyta, E. L., Bernardo, S. M., Parra, K. J., & Lee, S. A. (2019). Candida albicans Pma1p contributes to growth, pH homeostasis, and hyphal formation. Frontiers in Microbiology, 10, Article 1012. https://doi.org/10.3389/fmicb.2019.01012
18. Rasconi, S., Jobard, M., Jouve, L., & Sime-Ngando, T. (2009). Use of Calcofluor White for detection, identification, and quantification of phytoplanktonic fungal parasites. Applied and Environmental Microbiology, 75(8), 2545–2553. https://doi.org/10.1128/AEM.02211-08
19. Wachsmuth, E. D. (1988). A comparison of the highly selective fluorescence staining of fungi in tissue sections with Uvitex 2B and Calcofluor White M2R. Histochemical Journal, 20(4), 215–221. https://doi.org/10.1007/BF01747466
20. Wilhelmus, K. R., Osato, M. S., Font, R. L., Robinson, N. M., & Jones, D. B. (1986). Rapid diagnosis of Acanthamoeba keratitis using calcofluor white. Archives of Ophthalmology, 104(9), 1309–1312. https://doi.org/10.1001/archopht.1986.01050210063026
